Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: seamark zm
  • Model Number: ZM-L80
  • Condition: New
  • After-sales Service Provided: Overseas service center available
  • Application: to repairing LED TV screen display problem
  • Applicated LCD screen size: 995*1770mm (≤80 inch)
  • Applicated LCD thickness: 0.3-2.2mm
  • Working height: ≤50mm
  • Working weight: ≤20 kg
  • Power supply: AC 220V,50-60Hz,25A
  • Warranty: 1 year
  • Machine Size: 2245*1500*2247mm
  • Machine net weight: 900 kgs

Packaging & Delivery

Packaging Details strong wooden box
Delivery Time 10-15 working days


 Professional 4K LED TV screen laser repairing machine   ZM-L80  for TV LCD replacement



LCD laser repair machine (referred to as laser machine) is the most high-end repair technology machine in the LCD screen repair industry.
In addition to the COF loose welding, TAB (This error can be repaired with a bonding machine), other problems such as ITO break, short line, color line, bright spot, half-line, dotted line, multi-line, the laser machine can repair.
Laser machine with high efficiency, fixed rate, low cost (the same fault in the laser machine does not need replacement parts, and do not affect the repair rate), it is widely used as the main device screen repair of large-scale production factory, after sale and service company.

Youtube Link:


 Main Features

1. Point, line (length 50um), block (50um*50um) repair, repair LCD panel with or without polarizing film.
2. Image photographing, archiving and uploading.
3. Dual dispaly optical shutter red light and red frame.
4. Optical shutter size, lens magnification and laser power parameter storage and selection.
5. No fuse protection circuit breakers, overload current protection.
6. Max LCD panel screen size: 100 inch.

7.Easy to operate and maintenance.

Specification of ZM-L80

Working Platform
Working area:
905mm*1535mm*50mm (XYZ axis)
X, Y effective stroke:
Z axis range:
Working weight:
For LCD panel screen size:
Max 2214mm*1245mm (100 inch)
For LCD panel screen thick:
Working environment temperature:
Work environment relative humidity:
65 + / - 5% RH
operation mode:
X Y axis manual, Z axis manual
Optical Imaging System
Computer system:
Racks of computer, image acquisition card, Graphics Card
LCD Monitor:
24 inch LG monitor
Image Capture:
SXT 403 DC12V
400  ,800, 1600 multiple
Light source:
Adjustable, coaxial light sources, light spot and LED
Electrical Specification
Input Power:
AC  power 220V,50-60 Hz,25A
Air pressure:
1 Year
Laser System
Laser type
Q-Switch 5n /seconds
Output power:
800uJ/Pulse (100 times AVG)
Precision optical lens group:
5x (observed), 10x, 20x (special for LCD repair)
Adjust difference:
