Quick Details

  • Type: Other
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Seamark ZM
  • Model Number: ZM-R720
  • Voltage: AC 220V±10% 50/60 Hz
  • Current: Alternating Current
  • Rated Capacity: N/A
  • Rated Duty Cycle: N/A
  • Dimensions: L640*W630*H920 mm
  • Weight: 70kg
  • Usage: BGA Rework Station, BGA, GPU/ CPU, micro chips rework
  • Certification: CE ISO9001
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: Automatic BGA rework station for mobile laptop motherboard repair
  • Level: High automatic BGA rework station
  • Function: Desoldering & soldering BGA and components
  • Placement Accuracy: ±0.015MM
  • Optical System: HD CCD camera
  • Chip type: BGA, QGN, CSP, POP, QFN, Micro SMD, LED lamp beads
  • Temperature accuracy: ±2 degree
  • Temperature control: K Sensor, Closed loop
  • Application: Mobile laptop motherboard repair

Packaging & Delivery

Packaging Details Standard wooden carton packing. Safe for shipping.
Delivery Time Shpping out within 7 working days after received the payment
Product Description

Seamark ZM R720 automatic infrared BGA rework station for mobile laptop motherboard repair

Seamark ZM-R720 BGA/ LED rework station is a high performance automatic BGA rework station with HD camera Optical alignment system , CCD color optical vision system.

It can rework the BGA, LED, IC and other micro chipsets in high precision. Especialy suit for high precision motherboard rework, it is designed for precise rework.

Main features:

1. Widely used for BGA reballing chipset repairing in laptop, PS3,PS4,XBOX360, Moblie phone, etc.
2. Automatically Soldering, Desoldering, Romoving and Mounting the BGA Chip
3. HD Optical alignment system for precisely mounting BGA and components
4. Laser Positioning function for fast positioning the BGA Chip and motherboard
5. CCD color optical vision system, to enlarge the images up to maximum 230 times
6. Components mounting accuracy within 0.01mm , Repair success rate 99.9%
7. Rework micro BGA, VGA, CCGA, QFN, CSP, LGA, SMD, etc
8. Precise Temperature Control, accuracy within 2℃
9. Superior Safety Functions, with Emergency protection
10. User-friendly operation system
11. HP, Samsung & Sony also use this model for their repair service

Applications field of ZM-R720 LED / BGA rework station:

Mobile phone motherboard repair

Iphone, Samsung, Huawei, LG, Xiaomi etc.

Macbook, laptop, PC logic board repair

Apple, Lenovo, Asus, Thinkpad, Sony, HP,  Dell, Acer, Samsung, Hasee

Game console logic board repair
XBOX360, PS2, PS3, PS4
TV logic board repair
SAMSUNG,LGE, Hisense, TCL,SKYWORTH, SONY, AOC/TP Vision, Vizio, Haier, CHANGHONG, Panasonic,Sharp, KONKA

LED display module repair

Advertising indoor, outdoor, sports, signs led display module

Demo video link of ZM-R720 LED Rework:

Demo video link of ZM-R720 BGA Rework:


With high resolution optical alignment system, you can observe all the BGA chip point clearly , that's why the ZM-R720 will make BGA chip match with motherboard precisely.

Specification for Seamark ZM-R720 BGA rework station
Total Power
Max 5360W
AC 220V±10% 50/60 Hz
Top heater power
Bottom heater power
IR power
Hot air temp
400℃ (Max)
Preheating temp
400℃ (Max)
V-groove +laser positioning+ universal fixture
PCB size
Max 410×370 mm
Preheating size
Chip type
BGA, QGN, CSP, POP, QFN, Micro SMD, LED lamp beads
Chip size
Max 80×80mm Min 2×2 mm
L640×W630×H920 mm
Temperature sensor
1 piece
Net weight
Detailed Images

High definition Monitor

Use high resolution CCD camera to do precise alignment.

The alignment situation will be shown clearly on the monitor.

The CCD alignment system is automatic control

Mounting head

Five different size mounting head come with the machine.

You need to change the mounting head according to different size chips.

The photo shown at the right is the minimum mounting head for LED rework

IR Heater: Carbon fiber heating pipe & crystallite panel

Heating stably, quicker, and uniformly with long serve life.

Its heating effect is better than the ceramic infrared radiator.

Moreover, this model is more safe. Don't need to worry the micro components fall into the infrared heating area.

Joystick control

Alignment system controlled by joystick, no need setting complicated parameters.

Top air flow adjust can be adjusted more or less according to actual demands when you do the BGA, micro chips rework.

Seamark ZM R720 automatic infrared BGA rework station for mobile laptop motherboard repair

Our Service

1.Your inquiry will be replied in 8 hours.
2.Original Manufacture to customers, with competitive price.
3.We provide one year warranty, free training and wholelife technology support.
4.We can arrange the shipment by air, DHL,Fedex, UPS, and by Sea, etc for you, and will give you the tracking NO. after shipment.
5.Well-trained and Professional after-sales service team to support you.
6.Manual and Demo video CD will package with machine, It will show you how to use machine step by step.
7.Payment terms ,like T/T, Westerunion, PayPal is choosed by customers.

Pre-Sales Service

* Inquiry and consulting support. 8hours instant reply.

* Sample testing support.

* View our Factory.

After-Sales Service

* Free professional training.

*Warranty: One year.

* Engineers available to service machinery overseas.

Packing & Delivery

Packing of the ZM-R720 BGA rework station

Standard wooden carton package. Super strong.

It is safe during shipment.

Packing size: 77*78*103CM

Gross weight: 120KG

Shipping ways

By internation express such as DHL, UPS, TNT, etc.(One set)

By air (One set)

By sea (5sets above recommended)

We'll check the cheapest or most suitable shipping ways according to your requirements.

Our Company
The leading manufacturer of BGA/SMT rework, X-ray inspection system, TV LCD panel laser repair for 13 years in China.
Established in 2005, we have cooperated with many famous company & repairing centers at home and abroad. Such as DELL, Samsung, Hisense, Skyworth, Changhong, Flex, Foxconn company etc.

All of our BGA rework machine has CE certficate, strictly according to ISO 9001: 2008
High quality assurance is our task and also what we are doing now.


Photos with our agents

2017 Nepcon South China Exhibition

Representatives of cooperative partner


1. How about the package? Is it safe during the delivery?
All the bga rework station are packed by standard strong wooden carton.It is safe when shipping.

2. What is the delivery way? How many days will the machine arrrive us?
We will ship the machine by DHL,Fedex, UPS,etc (Door to Door Service), around 5 days to arrive.
Or by Air to your airport (Door to Airport Service ), around 3 days to arrive.
Or by Sea to the seaport, Minium CBM requirement : 1 CBM, around 30days to arrive.

3. What's the warranty you can offer to the machine? How about the after sales service?
1 year warranty free for spare parts, lifetime technical support.
We have professional after-sales team, if any question, assistant videos are also provided in after-sale service.

4. If we come to your factory, will you provide the free training?
Yes, warmly welcome you to visit our factory, we will arrange the professional technician to offer free training for you.

5. What is the payment way?

We accept the payment terms: Bank transfer, WesterUnion, Moneygram, Paypal, etc.
Bank transfer to our company account is reliable and prefered.

For more details of Seamark ZM R720 automatic infrared BGA rework station for mobile laptop motherboard repair, welcome to contact us directly. Looking forward to your inquiry.
