Quick Details
- Type: Other
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: Seamark ZM
- Model Number: ZM-R8650
- Voltage: 380V
- Current: N/A
- Rated Capacity: MAX 14700W
- Rated Duty Cycle: 50-100%
- Dimensions: 1350*1220*1770mm, 1350*1220*1770mm
- Weight: 1100KG
- Usage: Auto BGA Rework
- Certification: CE
- After-sales Service Provided: Engineers available to service machinery overseas
- Power supply: AC380V±10% 50/60Hz
- Top heater Power: 1200W
- Bottom heater Power: 1200w
- 3D IR heater Power: 12000W
- Positioning: Laser & CCD
- Model Type: Hot air and infrared bga rework station
- Available PCB size: Max 600*560mm ; Min 10*20 mm
- Work mode: Computer intelligence operations
Packaging & Delivery
| Packaging Details: | Standard Wooden Carton Package |
|---|---|
| Delivery Detail: | 2-7 working days after payment |
Specifications
bga rework station zhuomao ZM-8650
1.Full automatic Vision
2.Computer intelligence options
3.Accuracy <0.005mm
4.ISO9001&CE
2016 high precise full automatic bga rework station 5 sensors laser soldering machine
Product Description:
Specifications and technical parameters;
1 | Total Power | 14700W |
2 | Top heater | 1200W(1st heater) |
3 | Bottom heater | 1200W(2nd heater) |
4 | 3rd IR heater | 12000W(the left six IR heating plate can be controlled independently) |
5 | power | AC 380V±10% 50/60Hz |
6 | Electrical materials | Servo Drive( Panasonic)+Industrial Host+ Heating plate(Germany) |
7 | Optical system | Servo Drive+ Automatic Vision Alignment System (Panasonic) |
8 | Temperature control | K-type thermocouple (Closed Loop), independent heating, temperature precision within ±3 degree |
9 | Positioning | V-groove PCB support, and with external universal fixture |
10 | PCB size | Max 600×560mm ; Min 10×20 mm |
11 | BGA chip | 2×2-80×80mm |
12 | External temperature sensor | Five |
13 | Work Mode | Computer intelligence operations |
14 | Placement Accuracy | X, Y axis and the R angle with micrometer adjust, servo drive, accuracy within ± 0.025MM |
15 | Dimensions | 1350×1220×1770mm (LCD stand not included) |
16 | Net weight | 1100kg |
17 | Machine color | White |
ZM-R8650 main features:
3 independent control heaters:
the top and bottom heaters of ZM-R8650 can heat PCB from upper and bottom at the same time, and large preheating area can prevent the PCB board from deformation. The top and bottom heaters work independently, controlled by software, it makes the lead-free repair easily.The external sensors can detect temperature precisely, analyze and calibrate the real temperature curve accurately at any time;
Precise optical alignment system
ZM-R8650 adopt Panasonic automatic Vision Alignment System, it can get the image of BGA and the PCB through the CCD camera and collect them on the image positioning processing system, calculate the offset position and angle through image processing software, then re-transmission to motor drive of servo controller to correct the position, thus completing the BGA placement. positioning accuracy within ± 0.025MM; the image can zoom in, zoom out and micro adjust. Equipped with keyboard, mouse and 15 inch HD LCD monitor;
advanced intelligentized operation system
With comptuter operation, high accuracy K type close-loop thermocouple, and PID parameters automatic adjustment system;the top heaer and mount head are designed independently; the X,Y, Z axis and angle are controlled by panasonic servocontrol system to get accurate aligning point and heating point, with full automatic identify the height of BGA chips and mounting, it is of automatic positioning, mounting, soldering and desoldering function. there are 8 segments rising temperature and 8 activit temperatures.and it can save millions of temperature profiles and alignment parameters, for easy option desire profiles according to the different BGA chips.
Superior safety functions
With optical grating protection, when the machine is working, if the optical grating signal was blocked, then the machine will stop operation immediately ,it can protect the operator’ safety. When the servo motor collide with other objects, it will stop working also. It is of self-protect function; there are three color lamps to monitor the machine working at any time, it is of Superior safety protect function
1.About the Package, is it safe during the shipping?
All ccd BGA rework station are packed in Solid wooden box with foam, sticks and band to fix inside. It is safe enough when shipping.
2. Which way and how many days will the machine arrives?
We ship by DHL,Fed-ex, UPS,etc (Door to Door Service), 4~7 days to arrive; by Air to your nearest airport(Door to Airport Service ) 2~5 days to arrive; by Sea to your nearest seaport, 10~20~30~40 days to arrive. (different country different time)
3.About the Warranty, how long and how to do the after sales service?
1 year warranty free for spare parts, and Whole life technical support. We have professional technical team, for any question, assistant videos are also provided.
4.Can I operate it well, if I have no experience?
Our BGA machine is designed to use easily. Normally it will take you 2-3 hours to learn how to operate; if you are a technician, it will be much faster to learn. We will provide the English user manual for free , and the operation video is available.
5.Will you provide the free training?
Yes, warmly welcome you to visit our factory, we will arrange the free training for you. Also we provide online training.
6.About the Payment, which way is better ?
We accept the payment terms: Bank transfer, Western Union, Money gram, Paypal, etc.
Bank transfer to our company account is reliable and preferred.
If any question, you can send inquiry , or chat with us, we will be very pleased to support you!
Shenzhen Zhuomao Technology Co., Ltd. is founded in Shenzhen Since 2004. We are specialized in BGA Rework Station, X-RAY Inspection system, Reflow oven, Glue dispensing robot,Phone Lcd screen repair machine.
We has the industry's most powerful R & D team of 53 software engineers, mechanical engineers 15,and has the most efficient production team, we can customize the customer needs the product within 1 week.
we have passed the CE certification, ISO9001 quality system certification,also the FDA certification. our product has a good reputation and quality in the market.
A well established sales network and an after sales service system have built a strong reputation for us in China among high profile customers.
Our goal is to become a pioneer in SMT industry, if you are interested in our products, please contact us and we will provide you with the best quality products and the best service.
